SPARECRUX is NOT an authorized distributor for SCHNEIDER ELECTRIC

This product has been discontinued, and manufacturer warranty or support may no longer be available.

XCSPA593 | SCHNEIDER ELECTRIC | Interlock Safety Switch – Telemecanique Preventa XCS – ½″ NPT Entry”

₹ 5,152.12

₹ 4,366.20 (Excl. Tax)

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

XCSPA593

Fabricant d'équipement d'origine

SCHNEIDER ELECTRIC

Description
Range / Series Preventa XCS – Compact safety switch
Model XCSPA593
Contact Configuration 1 NC + 1 NO (slow-break, break-before-make)
Operator / Head Type Key‑operated turret head
Housing Material Polyamide (PA) – double insulated
Cable Entry 1 entry tapped for ½″ NPT
Terminal Type Screw‑clamp, 1 × 0.5…2 × 1.5 mm²
Mechanical Durability ≥ 1,000,000 cycles; B10d = 5 × 10⁶ (20‑year lifetime)
Operating Rate 10 cycles/minute max
Contact Currents (Ie) 6 A @ 120 V AC‑15; 3 A @ 240 V AC‑15; 0.55 A @ 125 V DC‑13; 0.27 A @ 250 V DC‑13
Rated Insulation Voltage (Ui) 300 V (UL/CSA), 500 V (IEC)
Impulse Withstand (Uimp) 6 kV (IEC 60947‑5‑1)
Positive Opening Yes, with NC contact (≥ 15 N withdrawal force)
Operating Temp. –25 °C to +70 °C
Protection IP67 per IEC 60529 / 60947‑5‑1
Shock / Vibration Shock: 10 g (11 ms), Vibration: 5 g (10–500 Hz)
Safety Performance Cat. 4 & PL e per ISO 13849‑1; SIL 3 per IEC 61508
Certifications UL 508, CSA C22.2 No 14, IEC 60947‑5‑1, ISO 13849‑1, ISO 14119
Weight ≈ 0.109 kg
SCHNEIDER ELECTRIC

XCSPA593 | SCHNEIDER ELECTRIC | Interlock Safety Switch – Telemecanique Preventa XCS – ½″ NPT Entry”

₹ 4,366.20
Range / Series Preventa XCS – Compact safety switch
Model XCSPA593
Contact Configuration 1 NC + 1 NO (slow-break, break-before-make)
Operator / Head Type Key‑operated turret head
Housing Material Polyamide (PA) – double insulated
Cable Entry 1 entry tapped for ½″ NPT
Terminal Type Screw‑clamp, 1 × 0.5…2 × 1.5 mm²
Mechanical Durability ≥ 1,000,000 cycles; B10d = 5 × 10⁶ (20‑year lifetime)
Operating Rate 10 cycles/minute max
Contact Currents (Ie) 6 A @ 120 V AC‑15; 3 A @ 240 V AC‑15; 0.55 A @ 125 V DC‑13; 0.27 A @ 250 V DC‑13
Rated Insulation Voltage (Ui) 300 V (UL/CSA), 500 V (IEC)
Impulse Withstand (Uimp) 6 kV (IEC 60947‑5‑1)
Positive Opening Yes, with NC contact (≥ 15 N withdrawal force)
Operating Temp. –25 °C to +70 °C
Protection IP67 per IEC 60529 / 60947‑5‑1
Shock / Vibration Shock: 10 g (11 ms), Vibration: 5 g (10–500 Hz)
Safety Performance Cat. 4 & PL e per ISO 13849‑1; SIL 3 per IEC 61508
Certifications UL 508, CSA C22.2 No 14, IEC 60947‑5‑1, ISO 13849‑1, ISO 14119
Weight ≈ 0.109 kg
