SPARECRUX is NOT an authorized distributor for SCHNEIDER ELECTRIC

This product has been discontinued, and manufacturer warranty or support may no longer be available.

XAP M1501 | SCHNEIDER ELECTRIC | die-cast empty control station - XAPM - Ø 22 - zinc alloy - 1 opening

₹ 6,726.00

₹ 5,700.00 (Excl. Tax)


Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

XAP M1501

Fabricant d'équipement d'origine

SCHNEIDER ELECTRIC

Description

Product Type Die‑cast zinc alloy empty control station enclosure
Cut-outs 1 × Ø22 mm (for pushbutton or pilot light)
Material Zinc alloy housing, blue lid
Dimensions (W×H×D) 80 × 80 × 74.5 mm usable depth 74.5 mm
Mounting Type Flush mount (panel)
Ingress Protection IP65 / IP69 / IP69K (dust, splash, wash‑down)
Weight ≈ 0.605 kg
Cable Entry Options Knock‑outs for ISO cable glands
Operating Temperature −40 °C … +70 °C
Standards / Certifications IEC 60529, NF C 20‑030, CE marking
Country of Origin Morocco
SCHNEIDER ELECTRIC

XAP M1501 | SCHNEIDER ELECTRIC | die-cast empty control station - XAPM - Ø 22 - zinc alloy - 1 opening

₹ 5,700.00
Product Type Die‑cast zinc alloy empty control station enclosure
Cut-outs 1 × Ø22 mm (for pushbutton or pilot light)
Material Zinc alloy housing, blue lid
Dimensions (W×H×D) 80 × 80 × 74.5 mm usable depth 74.5 mm
Mounting Type Flush mount (panel)
Ingress Protection IP65 / IP69 / IP69K (dust, splash, wash‑down)
Weight ≈ 0.605 kg
Cable Entry Options Knock‑outs for ISO cable glands
Operating Temperature −40 °C … +70 °C
Standards / Certifications IEC 60529, NF C 20‑030, CE marking
Country of Origin Morocco
