SPARECRUX is NOT an authorized distributor for SCHNEIDER ELECTRIC

This product has been discontinued, and manufacturer warranty or support may no longer be available.

TSXETY5103 | SCHNEIDER ELECTRIC | EtherNet TCP/IP Module, Modicon Premium, Modbus TCP, UNI-TELWAY, FactoryCast configurable, 530mA at 5VDC, 10Mbit/s

₹ 392,972.16

₹ 333,027.25 (Excl. Tax)

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

TSXETY5103

Fabricant d'équipement d'origine

SCHNEIDER ELECTRIC

Description
Transmission Speed 10/100 Mbit/s via RJ45 over a single twisted pair
Protocol Support Modbus TCP, Uni-Telway, SNMP agent, SMTP email alerts
Maximum Connections Up to 64 simultaneous TCP clients
Power Consumption 530 mA @ 5 V DC (fed by the PLC rack backplane)
LED Indicators Ethernet status: RUN, ERR, COL, TX/TR activity LEDs
Memory 8 MB user web page storage capability
Connectivity Services Global Data, I/O scanning, FDR server, NTP synchronization
Operating Conditions 0 – 60 °C, up to 95% RH (non-condensing), IP20 rating
Weight & Dimensions ~0.34 kg; rack-mount slim form factor
Lifecycle Status Active through December 2026; discontinued December 2020
SCHNEIDER ELECTRIC

TSXETY5103 | SCHNEIDER ELECTRIC | EtherNet TCP/IP Module, Modicon Premium, Modbus TCP, UNI-TELWAY, FactoryCast configurable, 530mA at 5VDC, 10Mbit/s

₹ 333,027.25
Transmission Speed 10/100 Mbit/s via RJ45 over a single twisted pair
Protocol Support Modbus TCP, Uni-Telway, SNMP agent, SMTP email alerts
Maximum Connections Up to 64 simultaneous TCP clients
Power Consumption 530 mA @ 5 V DC (fed by the PLC rack backplane)
LED Indicators Ethernet status: RUN, ERR, COL, TX/TR activity LEDs
Memory 8 MB user web page storage capability
Connectivity Services Global Data, I/O scanning, FDR server, NTP synchronization
Operating Conditions 0 – 60 °C, up to 95% RH (non-condensing), IP20 rating
Weight & Dimensions ~0.34 kg; rack-mount slim form factor
Lifecycle Status Active through December 2026; discontinued December 2020
