SPARECRUX is NOT an authorized distributor for BOSCH REXROTH

R166681420 | BOSCH REXROTH | Ball Runner Block, SKS, Size 20, Steel

₹ 14,757.34

₹ 12,506.22 (Excl. Tax)

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

R166681420

Fabricant d'équipement d'origine

BOSCH REXROTH

Description
Specification Details
Version Ball rail system
Nominal size [mm] 20
Format SKS - slimline, short, standard height
Model High-precision ball runner block
Material (profiled rail systems) Carbon steel
Preload class C1 - Low preload
Accuracy class N - Normal
Seal SS - Standard seal
Ball chain Without ball chain (standard)
Self-aligning Without self-alignment
Width of runner block [mm] 44.0
Length of runner block [mm] 57.3
Height of runner block [mm] 25.35
Height runner block with guide rail [mm] 30.0
Lubrication Pre-lubricated, preserved
Maximum acceleration rate amax [m/s²] 500.0
Maximum permissible linear speed vmax [m/s] 5.0
Permissible ambient temperature -10 °C ... +80 °C
Friction coefficient μ 0.002 ... 0.003
Weight [kg] 0.25
Dynamic load capacity C50 [N] 19400.0
Dynamic load capacity C100 [N] 15400.0
Static load capacity C0 [N] 16500.0
Dynamic torsional moment load capacity Mt50 [Nm] 250.0
Dynamic torsional moment load capacity Mt100 [Nm] 200.0
BOSCH REXROTH

R166681420 | BOSCH REXROTH | Ball Runner Block, SKS, Size 20, Steel

₹ 12,506.22
Specification Details
Version Ball rail system
Nominal size [mm] 20
Format SKS - slimline, short, standard height
Model High-precision ball runner block
Material (profiled rail systems) Carbon steel
Preload class C1 - Low preload
Accuracy class N - Normal
Seal SS - Standard seal
Ball chain Without ball chain (standard)
Self-aligning Without self-alignment
Width of runner block [mm] 44.0
Length of runner block [mm] 57.3
Height of runner block [mm] 25.35
Height runner block with guide rail [mm] 30.0
Lubrication Pre-lubricated, preserved
Maximum acceleration rate amax [m/s²] 500.0
Maximum permissible linear speed vmax [m/s] 5.0
Permissible ambient temperature -10 °C ... +80 °C
Friction coefficient μ 0.002 ... 0.003
Weight [kg] 0.25
Dynamic load capacity C50 [N] 19400.0
Dynamic load capacity C100 [N] 15400.0
Static load capacity C0 [N] 16500.0
Dynamic torsional moment load capacity Mt50 [Nm] 250.0
Dynamic torsional moment load capacity Mt100 [Nm] 200.0
