SPARECRUX is NOT an authorized distributor for SCHNEIDER ELECTRIC

This product has been discontinued, and manufacturer warranty or support may no longer be available.

A9K24110 | SCHNEIDER ELECTRIC | Miniature Circuit Breaker Acti9 IK60N 1P 10A C curve 6000A

₹ 403.56

₹ 342.00 (Excl. Tax)

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

A9K24110

Fabricant d'équipement d'origine

SCHNEIDER ELECTRIC

Description
Series / Range Acti9 iK60 (Acti9 iK60N)
Type Miniature Circuit Breaker (MCB), thermal‑magnetic trip
Poles 1 Pole (1P) – Single pole
Rated Current (In) 10 A @ 30 °C
Network Type AC, 50/60 Hz
Trip Curve C‑Curve (5…10 × In magnetic trip)
Breaking Capacity (Icn/Ics) 6000 A @ 230 VAC (100 % Ics)
Rated Operational Voltage (Ue) 230 VAC @ 50/60 Hz
Rated Insulation Voltage (Ui) 440 VAC
Impulse Withstand Voltage (Uimp) 4 kV
Control / Handle Type Toggle switch with ON/OFF indication
Isolation Capability Yes (per EN/IEC 60898‑1)
Durability (Mechanical) 20,000 operations
Durability (Electrical) 10,000 operations
Mounting Mode Clip‑on on 35 mm DIN rail or screw‑mounted panel
Connection Pitch / Width 18 mm width (2 × 9 mm modules)
Terminal Type Tunnel terminals (top or bottom), rigid 1–25 mm² or flexible 1–16 mm²
Wire Stripping Length 14 mm
Tightening Torque 2 N·m (top or bottom terminals)
Locking Feature Padlocking possible
Weight Approx. 100 g
Color White
Protection Rating IP20 (IEC 60529)
Pollution Degree 2 (IEC/EN 60898‑1)
Overvoltage Category III
Operating Temperature −25 °C to +60 °C
Storage Temperature −40 °C to +85 °C
Standards & Certifications EN/IEC 60898‑1; Green Premium, RoHS & REACh compliant
Environmental Footprint Approximately 2 kg CO₂-eq per product lifecycle
