SPARECRUX is NOT an authorized distributor for FESTO

573606 | FESTO | Valve Terminal VTUG

₹ 71,862.83

₹ 60,900.70 (Excl. Tax)


Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

573606

Fabricant d'équipement d'origine

FESTO

Description

Specification Details
Electrical control AP interface
Individual connection Fieldbus
I-Port IO-Link®
Multi-pin plug
Electrical I/O system no
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Pilot medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required)
Media temperature -5 °C ... 60 °C
Ambient temperature -5 °C ... 60 °C
Storage temperature -10 °C ... 60 °C
Degree of protection IP40, IP65, IP67, IP69K, NEMA 4X
Corrosion resistance class CRC 2 - Moderate corrosion stress
Vibration resistance Transport application test with severity level 2 to FN 942017-4 and EN 60068-2-6
Shock resistance Shock test with severity level 2 to FN 942017-5 and EN 60068-2-27
Operating pressure -0.09 MPa ... 1 MPa
Operating pressure -0.9 bar ... 10 bar
Pilot pressure 0.15 MPa ... 0.8 MPa
Pilot pressure 1.5 bar ... 8 bar
Operating pressure for valve terminal with internal pilot air supply 1.5 bar ... 8 bar
LABS (PWIS) conformity VDMA24364-B1/B2-L
CE mark (see declaration of conformity) To EU EMC Directive, In accordance with EU RoHS Directive
UKCA marking (see declaration of conformity) To UK instructions for EMC, To UK RoHS instructions
KC mark KC-EMV
Approval RCM trademark, c UL us - Recognized (OL)
Certificate issuing authority UL MH19482
Note on materials RoHS-compliant
Material seals HNBR, NBR
Valve terminal structure Fixed grid
Max. number of valve positions 24
Max. number of pressure zones 13
Type of actuation Electric
Valve function 2x3/2-way, monostable, closed
2x3/2-way, open, monostable
2x3/2-way, open/closed, monostable
3/2-way, closed, monostable
3/2 open, monostable
5/2 bistable
5/2-way, monostable
5/3-way, pressurised
5/3 exhausted
5/3 closed
Design Piston gate valve
Sealing principle Soft
Type of piloting Pilot actuated
Valve size 18 mm
Pilot air supply External, Internal
Max. standard nominal flow rate 330 l/min at 10 mm
630 l/min at 14 mm
1200 l/min at 18 mm
Standard nominal flow rate (standardised to DIN 1343) 130 l/min ... 1150 l/min
