SPARECRUX is NOT an authorized distributor for FESTO

534339 | FESTO | One-way Flow Control Valve GRLA-1/4-QS-8-RS-D

₹ 980.41

₹ 830.86 (Excl. Tax)

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

534339

Fabricant d'équipement d'origine

FESTO

Description
Parameter Specification
Valve function One-way flow control function
Pneumatic connection, port 1 QS-8
Pneumatic connection, port 2 G1/4
Adjustment component Knurled screw
Type of mounting Screw-in via male thread
Standard nominal flow rate (flow control direction) 475 l/min
Standard nominal flow rate (blocked direction) 325 l/min ... 500 l/min
Operating pressure 0.2 bar ... 10 bar
Operating pressure (complete temp. range) 0.2 bar ... 10 bar
Standard flow rate (control direction, 0.6→0 MPa) 720 l/min
Standard flow rate (non-return direction, 0.6→0 MPa) 610 l/min ... 760 l/min
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Lubricated operation Possible (lubricated operation required if used)
LABS (PWIS) conformity VDMA24364-B1/B2-L
Cleanroom class Class 4 (ISO 14644-1)
Storage temperature -10 °C ... 40 °C
Media temperature -10 °C ... 60 °C
Nominal torque 5 Nm
Product weight 50 g
Note on materials RoHS-compliant
Material seals NBR
Material hollow bolt Wrought aluminium alloy, anodised
Material release ring POM
FESTO
