195999 | FESTO | Round Cylinder DSNU-40-320-P-A

₹ 5,453.33

₹ 4,621.47 (Excl. Tax)


Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

195999

Fabricant d'équipement d'origine

FESTO

Description

Parameter Details
Stroke 320 mm
Piston diameter 40 mm
Piston rod thread M12x1.25
Cushioning Elastic cushioning rings/plates at both ends
Mounting position optional
Design Piston, Piston rod, Cylinder barrel
Position detection Via proximity switch
Symbol 00991217
Operating pressure 0.1 MPa ... 1 MPa / 1 bar ... 10 bar
Mode of operation Double-acting
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (required if lubricated)
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -20 °C ... 80 °C
Impact energy in end positions 0.7 J
Theoretical force at 0.6 MPa (return stroke) 633.3 N
Theoretical force at 0.6 MPa (advance stroke) 752.9 N
Moving mass 742 g
Product weight 1429 g
Type of mounting With accessories
Pneumatic connection G1/4
Note on materials RoHS-compliant
Material cover Wrought aluminium alloy
Material seals NBR, TPE-U(PU)
Material piston rod High-alloy steel
Material cylinder barrel High-alloy stainless steel
