SPARECRUX is NOT an authorized distributor for FESTO

175753 | FESTO | Compact Cylinder ADVU-125-25-P-A

₹ 26,705.61

₹ 22,631.87 (Excl. Tax)

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

175753

Fabricant d'équipement d'origine

FESTO

Description
Parameter Value
Stroke 25 mm
Piston diameter 125 mm
Piston rod thread M16
Cushioning Elastic cushioning rings/plates at both ends
Mounting position Optional
Mode of operation Double-acting
Piston-rod end Female thread
Design Piston, Piston rod
Position detection Via proximity switch
Symbol 00991217
Variants Piston rod at one end
Operating pressure 0.05 MPa ... 1 MPa
Operating pressure 0.5 bar ... 10 bar
Operating pressure 7.25 psi ... 145 psi
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (lubricated operation always required if used)
Corrosion resistance class (CRC) 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -20 °C ... 80 °C
Impact energy in end positions 3.3 J
Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke 6881 N
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke 7363 N
Moving mass for 0 mm stroke 1317 g
Additional moving mass per 10 mm stroke 63 g
Basic weight for 0 mm stroke 3426 g
Additional weight per 10 mm stroke 168 g
Type of mounting With through-hole, with accessories
Pneumatic connection G1/4
Material collar screws Galvanised steel
Material cover Painted die-cast aluminium
Material dynamic seals NBR, TPE-U (PU)
Material piston rod High-alloy steel
Material cylinder barrel Wrought aluminium alloy
