SPARECRUX is NOT an authorized distributor for FESTO

This product has been discontinued, and manufacturer warranty or support may no longer be available.

161167 | FESTO | Proportional-pressure Regulator MPPE-3-1/4-6-010-B

₹ 70,526.89

₹ 59,768.55 (Excl. Tax)


Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

161167

Fabricant d'équipement d'origine

FESTO

Description

Feature Specification
Part Number 161167
Product Name MPPE-3-1/4-6-010-B
Valve Function 3-way proportional pressure regulator (closed)
Actuation Type Electrical
Sealing Principle Soft
Mounting Position Any
Design Pilot-controlled piston control valve
Operating Pressure ≤ 8 bar
Pressure Regulation Range 0 bar to 6 bar
Inlet Pressure 7 bar to 8 bar
Max. Pressure Hysteresis 0.04 bar
Switching Time (Off) 260 ms
Switching Time (On) 150 ms
Operating Voltage Range 18 V to 30 V DC
Reference Voltage 10 V
Residual Ripple 10%
Setpoint/Actual Values Voltage type 0 - 10 V
Operating Medium Compressed air (ISO 8573-1:2010 [7:4:4]), inert gases
Lubricated Operation Possible (required for further use)
Corrosion Resistance Class CRC 2 - Moderate corrosion stress
Temperature of Medium 0 °C to 60 °C
Degree of Protection IP65
Ambient Temperature 0 °C to 50 °C
Product Weight 920 g
Electrical Connection 8-pin M16x0.75 plug (DIN 45326, round design)
Mounting Type With through-hole
Pneumatic Connections G1/4 (ports 1, 2, and 3)
Housing Material Wrought aluminum alloy
Diaphragm Material NBR
FESTO
