SPARECRUX is NOT an authorized distributor for FESTO

This product has been discontinued, and manufacturer warranty or support may no longer be available.

159590 | FESTO | Service Unit FRC-1/2-D-MIDI

₹ 9,438.74

₹ 7,998.93 (Excl. Tax)


Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

159590

Fabricant d'équipement d'origine

FESTO

Description

Feature Details
Size Midi
Series D
Actuator lock Rotary knob with detent
Mounting position Vertical +/-5°
Condensate drain Manually rotating
Design Filter regulator with pressure gauge; Proportional standard mist lubricator
Max. condensate volume 43 ml
Grade of filtration 40 µm
Bowl guard Metal bowl guard
Symbol 00991549
Pressure gauge With pressure gauge (analog)
Operating pressure 0.1 MPa ... 1.6 MPa
1 bar ... 16 bar
Pressure regulation range 0.5 bar ... 12 bar
Max. pressure hysteresis 0.02 MPa / 0.2 bar / 2.9 psi
Standard nominal flow rate (DIN 1343) 2600 l/min
Operating medium Compressed air to ISO 8573-1:2010 [-:9:-], Inert gases
Note on operating and pilot medium Lubricated operation possible (required if applied)
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Air purity class at output Compressed air to ISO 8573-1:2010 [7:8:-], Inert gases
Media temperature -10 °C ... 60 °C
Ambient temperature -10 °C ... 60 °C
Product weight 1440 g
Type of mounting In-line installation
With accessories Yes
Pneumatic connection, port 1 G1/2
Pneumatic connection, port 2 G1/2
Note on materials RoHS-compliant
Material housing Die-cast zinc
Material bowl PC
