SPARECRUX is NOT an authorized distributor for FESTO

159502 | FESTO | Precision Pressure Regulator LRP-1/4-10

₹ 6,443.01

₹ 5,460.18 (Excl. Tax)


Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

159502

Fabricant d'équipement d'origine

FESTO

Description

Parameter Value
Actuator lock Rotary knob with detent
Mounting position Optional
Design Piloted precision diaphragm control valve
Controller function Output pressure constant
Secondary venting With secondary venting
Symbol 00991540
Pressure gauge/display Prepared for G1/8
Operating pressure 0.1 MPa ... 1.2 MPa (1 bar ... 12 bar)
Pressure regulation range 0.1 bar ... 10 bar
Inlet pressure 1 1 bar ... 12 bar
Max. pressure hysteresis 0.02 bar
Standard nominal flow rate 2300 l/min (DIN 1343)
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4], Inert gases
Note on operating and pilot medium Lubricated operation not possible
LABS (PWIS) conformity VDMA24364-B1/B2-L
Media temperature -10 °C ... 60 °C
Ambient temperature -10 °C ... 60 °C
Product weight 310 g
Type of mounting With accessories
Pneumatic connection, port 1 G1/4
Pneumatic connection, port 2 G1/4
Note on materials RoHS-compliant
Material seals NBR
Material housing Aluminium
