SPARECRUX is NOT an authorized distributor for FESTO

151215 | FESTO | One-way Flow Control Valve GR-1/8-B

₹ 835.56

₹ 708.10 (Excl. Tax)


Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

151215

Fabricant d'équipement d'origine

FESTO

Description

Property Value
Valve function One-way flow control function
Pneumatic connection, port 1 G1/8
Pneumatic connection, port 2 G1/8
Adjustment component Knurled screw
Type of mounting With through-hole
Standard nominal flow rate in flow control direction 210 l/min
Standard nominal flow rate in blocked direction 180 l/min ... 275 l/min
Operating pressure 0.5 bar ... 10 bar
Ambient temperature -20 °C ... 60 °C
Material housing Wrought aluminium alloy
Explosion protection See certificate for details (Zones 1, 2, 21, 22 ATEX)
Mounting position Optional
Symbol 00991453
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (lubricated operation required if used)
LABS (PWIS) conformity VDMA24364-B1/B2-L
Media temperature -20 °C ... 60 °C
Nominal size 3 mm
Product weight 31 g
Note on materials RoHS-compliant
Material seals NBR
Material sleeve POM
Material adjusting screw High-alloy steel
Material nut Wrought aluminium alloy
