SPARECRUX is NOT an authorized distributor for MOXA

TN-5305 | MOXA | Ethernet Switch with 5 10/100BaseT Ports And With M12 Connectors

₹ 43,831.10

₹ 37,145.00 (Excl. Tax)


ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

TN-5305

الشركة المصنعة للمعدات الأصلية

MOXA

وصف

Parameter Specification
Type Unmanaged Ethernet Switch
Ports 5 × 10/100BaseT(X) (M12 D‑coded connectors)
Protection / Housing IP67 (dust/water resistant
Operating Voltage 18 to 30 VAC or 24 to 36 VDC
Input Current ~0.1 A @ 24 VDC; ~0.08 A @ 36 VDC
Dimensions (L × W × H) 60 × 125 × 29.6 mm
Weight ~270 g (packaged)
Operating Temperature –25 °C to 60 °C (standard); –40 °C to 75 °C for “T” variant
Mounting Options DIN‑rail (optional kit), Wall mount
Standards & Certifications EN 50155, EN 50121‑4, shock & vibration per IEC/EN standards
MOXA

TN-5305 | MOXA | Ethernet Switch with 5 10/100BaseT Ports And With M12 Connectors

₹ 37,145.00
Parameter Specification
Type Unmanaged Ethernet Switch
Ports 5 × 10/100BaseT(X) (M12 D‑coded connectors)
Protection / Housing IP67 (dust/water resistant
Operating Voltage 18 to 30 VAC or 24 to 36 VDC
Input Current ~0.1 A @ 24 VDC; ~0.08 A @ 36 VDC
Dimensions (L × W × H) 60 × 125 × 29.6 mm
Weight ~270 g (packaged)
Operating Temperature –25 °C to 60 °C (standard); –40 °C to 75 °C for “T” variant
Mounting Options DIN‑rail (optional kit), Wall mount
Standards & Certifications EN 50155, EN 50121‑4, shock & vibration per IEC/EN standards
عرض المنتج
