SPARECRUX is NOT an authorized distributor for FABCO-AIR

THP1-1/8X12FF | FABCO-AIR | Pneumatic Cylinders

₹ 19,193.93

₹ 16,266.04 (Excl. Tax)


ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

THP1-1/8X12FF

الشركة المصنعة للمعدات الأصلية

FABCO-AIR

وصف

Specification Details
Primary Brand Fabco-Air
Main Function Pneumatic Cylinder
Product Series / Family Name Hi-Power
Sub-Range Name THP Series
Bore Size 1-1/8" (B1-1/8")
Stroke Length 12" (S12")
Functions Double-acting maximum stroke / minimum length tie-rod air cylinder actuator
Design Single Rod
Pressure Range 15 psi min. / 250 psi max.
Shape Rectangular
Connection Type 5/16"-24 UNF-2B Female Threaded Rod-End
2 x 1/8" NPT Threaded Pneumatic Ports
Mounting Mode Front Face Mounting with Fabco Pattern
Material Aluminium Body (Hard Anodized ID / Clear Anodized OD)
Stainless Steel Piston Rod
Aluminium Piston
Buna-N U-Cup Seals
Steel Piston Bolt
Stainless Steel Tie Rods
Plated Steel Nuts
PTFE Piston Bearing
Duralon Rod Bearing
Pre-lubricated with Magnalube-G Grease
Black Anodized Aluminium Rod and Cap End Heads
Black Anodized Aluminium Cap End Plug
Anodized Aluminium Piston Rod Bushing
Operating Temperature -25...+250 °F / -32...+121 °C
FABCO-AIR
