SPARECRUX is NOT an authorized distributor for SCHMERSAL

RSS16-D-R-STSH | SCHMERSAL | RFID Non-Contact Safety Switch

₹ 5,605.00

₹ 4,750.00 (Excl. Tax)


ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

RSS16-D-R-STSH

الشركة المصنعة للمعدات الأصلية

SCHMERSAL

وصف

Attribute Details
Brand Schmersal
Model RSS16-D-R-ST8H
Part Number 103004338
Product Type RFID Safety Sensor
Technology RFID-coded non-contact safety switch
Coding Universal Coding
Latching Yes (magnetic latching)
Connection M12, 8-pin connector
Safety Category Cat. 4, PL e, SIL 3
Switching Distance (Sn) 15 mm
Assured ON Distance (Sao) 5 mm
Assured OFF Distance (Sar) 30 mm
Output Type 2 Safety Outputs + 1 Diagnostic Output
Supply Voltage 24 V DC
Housing Material Glass-fibre reinforced thermoplastic
Protection Rating IP65 / IP66 / IP67
Operating Temperature -28°C to +70°C
Dimensions 91 × 52 × 30 mm
Application Safety doors, guards, machine interlocks
