SPARECRUX is NOT an authorized distributor for TURCK

PKG 4M-10/CS10022 | TURCK | Actuator and Sensor Cable M8, Female, Straight, 4-pin

₹ 5,396.49

₹ 4,573.30 (Excl. Tax)


ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

PKG 4M-10/CS10022

الشركة المصنعة للمعدات الأصلية

TURCK

وصف

Parameter Value
Primary brand Turck
Main function Cable
Product series / family name Connectivity > Cables > Open-ended cordsets > straight connector to bare leads
Sub-range name M8 picofast to bare leads
Functions Single-ended mating cable / cordset
Design CL2 rated
Number of circuits 4-wire
Rated current 2A
Color Yellow sheath
Rated voltage (AC) 125Vac
Diameter 4.4 mm cable sheath O.D.
Connection type 4-pin M8 picofast female connector (M8x1 threaded coupl. nut), bare end flying leads
Cross-section 4 x #26AWG
Length 10 m (32 ft)
Degree of protection IP67, NEMA 1, NEMA 3, NEMA 4, NEMA 6P
Dimensions 10 m length
Material Nickel-plated brass coupl. nut, PVC jacket
Contents Uses cable type #RF50697-M
Order code / Manufacturer SKU SKUU0063-0
Manufacturer product status Commercialized
Equivalent to PKG4M-10/CS10022, PKG-4M-10/CS10022, PKG4M10CS10022
Compliant with standard(s) UL, CSA, AWM, CL2
TURCK

PKG 4M-10/CS10022 | TURCK | Actuator and Sensor Cable M8, Female, Straight, 4-pin

₹ 4,573.30
Parameter Value
Primary brand Turck
Main function Cable
Product series / family name Connectivity > Cables > Open-ended cordsets > straight connector to bare leads
Sub-range name M8 picofast to bare leads
Functions Single-ended mating cable / cordset
Design CL2 rated
Number of circuits 4-wire
Rated current 2A
Color Yellow sheath
Rated voltage (AC) 125Vac
Diameter 4.4 mm cable sheath O.D.
Connection type 4-pin M8 picofast female connector (M8x1 threaded coupl. nut), bare end flying leads
Cross-section 4 x #26AWG
Length 10 m (32 ft)
Degree of protection IP67, NEMA 1, NEMA 3, NEMA 4, NEMA 6P
Dimensions 10 m length
Material Nickel-plated brass coupl. nut, PVC jacket
Contents Uses cable type #RF50697-M
Order code / Manufacturer SKU SKUU0063-0
Manufacturer product status Commercialized
Equivalent to PKG4M-10/CS10022, PKG-4M-10/CS10022, PKG4M10CS10022
Compliant with standard(s) UL, CSA, AWM, CL2
