SPARECRUX is NOT an authorized distributor for HILSCHER

NT 50-RS-EN | HILSCHER | Gateway Protocal Converter

₹ 37,543.72

₹ 31,816.71 (Excl. Tax)


ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

NT 50-RS-EN

الشركة المصنعة للمعدات الأصلية

HILSCHER

وصف

Specification Details
Product Name NT 50-RS-EN
Part Number 1750.110
Brief Description Gateway RS-232/422/485 to Ethernet
Communication Controller netX 50
Integrated Memory (RAM) 8 MB SDRAM
Integrated Memory (FLASH) 4 MB Serial Flash
Supply Voltage 24 V ± 6 V DC
Current Consumption at 24V 72 mA (typical)
Connector Type (Power) Mini-COMBICON, 2-pin
Communication Interface X2 Serial Interface: RS-232, RS-422, RS-485; Connector: RJ45 (Ethernet & serial together)
Communication Interface X3 Ethernet: 10BASE-T/100BASE-TX, isolated; Connector: 1 × RJ45
Diagnostic Interface Ethernet, 4-pin; Connector: RJ45 socket
LED Displays SYS (System), APL (Application), COM (Communication), LINK/ACT (Link & Activity)
Ambient Temperature (Operation) 0 °C … +60 °C
Ambient Temperature (Storage) -40 °C … +85 °C
Relative Humidity 10 % … 95 %, non-condensing
Altitude 0 m … 2000 m
Device Dimensions (L × W × H) 100 × 26 × 66 mm (without connector)
Weight Approx. 80 g
Degree of Protection IP20
HILSCHER

NT 50-RS-EN | HILSCHER | Gateway Protocal Converter

₹ 31,816.71
Specification Details
Product Name NT 50-RS-EN
Part Number 1750.110
Brief Description Gateway RS-232/422/485 to Ethernet
Communication Controller netX 50
Integrated Memory (RAM) 8 MB SDRAM
Integrated Memory (FLASH) 4 MB Serial Flash
Supply Voltage 24 V ± 6 V DC
Current Consumption at 24V 72 mA (typical)
Connector Type (Power) Mini-COMBICON, 2-pin
Communication Interface X2 Serial Interface: RS-232, RS-422, RS-485; Connector: RJ45 (Ethernet & serial together)
Communication Interface X3 Ethernet: 10BASE-T/100BASE-TX, isolated; Connector: 1 × RJ45
Diagnostic Interface Ethernet, 4-pin; Connector: RJ45 socket
LED Displays SYS (System), APL (Application), COM (Communication), LINK/ACT (Link & Activity)
Ambient Temperature (Operation) 0 °C … +60 °C
Ambient Temperature (Storage) -40 °C … +85 °C
Relative Humidity 10 % … 95 %, non-condensing
Altitude 0 m … 2000 m
Device Dimensions (L × W × H) 100 × 26 × 66 mm (without connector)
Weight Approx. 80 g
Degree of Protection IP20
