SPARECRUX is NOT an authorized distributor for PIZZATO

نفذ

NA G022KC-DN2 | PIZZATO | Modular Prewired Switch With Adjustable Shaped Metal Revolving Lever Diam. 14 Roller

₹ 6,136.00

₹ 5,200.00 (Excl. Tax)


ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

NA G022KC-DN2

الشركة المصنعة للمعدات الأصلية

PIZZATO

وصف

Parameter Specification
Manufacturer Pizzato Elettrica
Series NA (Modular Pre-wired Safety / Position Switch)
Model NAG022KCDN2
Product Type Pre-wired limit switch / safety position switch
Contact Configuration 2 NC (G02 contact block)
Contact Type Snap-action (quick break)
Housing Material Metal (die-cast / painted)
Actuator Type Roller lever (rotating lever mechanism)
Protection Rating IP67 / IP69K
Operating Temperature -25°C to +80°C
Electrical Connection Pre-wired cable (DN2 variant)
Cable Type PVC 5x0.75 mm² (typical NA series)
Fixing Standard industrial mounting (20 mm spacing)
Mechanical Life Up to 1,000,000 cycles
Application Machine safety, door interlocks, automation positioning
