SPARECRUX is NOT an authorized distributor for SCHNEIDER ELECTRIC

This product has been discontinued, and manufacturer warranty or support may no longer be available.

LV431681 | SCHNEIDER ELECTRIC | Circuit Breaker Compact NSX250H, 70 kA at 415 VAC, TMD Trip Unit 200 A, 4 Poles 3d

₹ 81,688.39

₹ 69,227.45 (Excl. Tax)


ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

LV431681

الشركة المصنعة للمعدات الأصلية

SCHNEIDER ELECTRIC

وصف

Manufacturer Schneider Electric – ComPact NSX series
Product Type MCCB with fixed thermal-magnetic trip unit (TM‑D)
Poles 4P (3t, 3‐phase + neutral)
Rated Current (In) 200 A @ 40 °C
Rated Operational Voltage (Ue) 690 VAC, 50/60 Hz
Breaking Capacity (Icu) 70 kA @ 380–415 VAC; 100 kA @ 240 VAC (IEC/NEMA)
Service Breaking Capacity (Ics) 70 kA @ 380–415 VAC; 100 kA @ 220–240 VAC (IEC)
Rated Insulation Voltage (Ui) 800 VAC
Impulse Withstand Voltage (Uimp) 8 kV
Usage Category Category A (IEC 60947‑2)
Suitability for Isolation Yes
Mechanical Durability 20,000 cycles
Electrical Durability 10,000 cycles @ In and IEC conditions
Mounting Style Fixed backplate mounting, front terminals
Connection Pitch 35 mm
Dimensions (H×W×D) 161 × 140 × 86 mm
Weight ≈ 2.8 kg
Standards & Certifications IEC 60947‑2; UL, CSA, CCC, EAC; Green Premium
Operating Temp. −25 °C to +70 °C
