SPARECRUX is NOT an authorized distributor for OMRON

E2E-C04S12-CJ-B1 | OMRON | Proximity Sensor

₹ 2,189.05

₹ 1,855.13 (Excl. Tax)


ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

E2E-C04S12-CJ-B1

الشركة المصنعة للمعدات الأصلية

OMRON

وصف

Product Attribute Attribute Value
Sensing Head Size 4 mm diameter
Type Cylinder type, Shielded
Power Source DC Three-wire models
Sensing Distance 1.2 mm ±10%
Setting Distance 0 to 0.84 mm
Differential Distance 15% max. of sensing distance
Sensing Object Ferrous metal (Sensitivity lowers with non-ferrous metals)
Standard Sensing Object Iron 4 × 4 × 1 mm
Response Frequency 4 kHz
Power Supply Voltage 10 to 30 VDC (Ripple p-p 10% included)
Operating Voltage Range 10 to 30 VDC
Current Consumption 10 mA max.
Control Output (Output Type) PNP Open Collector
Control Output (Switching Capacity) 100 mA max.
Control Output (Residual Voltage) 2 V max. (at 100 mA load, 2 m cable length)
Indicator Operation Indicator (Yellow)
Operation Mode Normally Open (NO)
OMRON

E2E-C04S12-CJ-B1 | OMRON | Proximity Sensor

₹ 1,855.13
Product Attribute Attribute Value
Sensing Head Size 4 mm diameter
Type Cylinder type, Shielded
Power Source DC Three-wire models
Sensing Distance 1.2 mm ±10%
Setting Distance 0 to 0.84 mm
Differential Distance 15% max. of sensing distance
Sensing Object Ferrous metal (Sensitivity lowers with non-ferrous metals)
Standard Sensing Object Iron 4 × 4 × 1 mm
Response Frequency 4 kHz
Power Supply Voltage 10 to 30 VDC (Ripple p-p 10% included)
Operating Voltage Range 10 to 30 VDC
Current Consumption 10 mA max.
Control Output (Output Type) PNP Open Collector
Control Output (Switching Capacity) 100 mA max.
Control Output (Residual Voltage) 2 V max. (at 100 mA load, 2 m cable length)
Indicator Operation Indicator (Yellow)
Operation Mode Normally Open (NO)
