SPARECRUX is NOT an authorized distributor for ELMEX

DPBB50 | ELMEX | High-current busbar terminal block

₹ 2,006.00

₹ 1,700.00 (Excl. Tax)


ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

DPBB50

الشركة المصنعة للمعدات الأصلية

ELMEX

وصف

Type High-current busbar terminal block
Housing Material Polyamide 6.6
Clamping Material Nickel-plated brass (NAP)
Standard Color Gray (also available in Red, Yellow, Blue, Black, Green, Khaki)
Mounting Type DIN Rail (TS 35/7.5, TS 35/15, TS 32)
Conductor Size (Solid Wire) 10 mm² to 50 mm²
Conductor Size (Stranded Wire) 10 mm² to 50 mm²
Rated Voltage (IEC Standard) 1000 V AC/DC
Rated Voltage (UL Standard) 1000 V
Rated Current (IEC Standard) 150 A
Rated Current (UL Standard) 130 A
Rated Cross-Section 50 mm²
Short-Time Withstand Current 6 kA
Rated Impulse Withstand Voltage 12 kV
ELMEX

DPBB50 | ELMEX | High-current busbar terminal block

₹ 1,700.00
Type High-current busbar terminal block
Housing Material Polyamide 6.6
Clamping Material Nickel-plated brass (NAP)
Standard Color Gray (also available in Red, Yellow, Blue, Black, Green, Khaki)
Mounting Type DIN Rail (TS 35/7.5, TS 35/15, TS 32)
Conductor Size (Solid Wire) 10 mm² to 50 mm²
Conductor Size (Stranded Wire) 10 mm² to 50 mm²
Rated Voltage (IEC Standard) 1000 V AC/DC
Rated Voltage (UL Standard) 1000 V
Rated Current (IEC Standard) 150 A
Rated Current (UL Standard) 130 A
Rated Cross-Section 50 mm²
Short-Time Withstand Current 6 kA
Rated Impulse Withstand Voltage 12 kV
