SPARECRUX is NOT an authorized distributor for ELMEX

CUDD4 | ELMEX | Double-Level Terminal Block

₹ 271.40

₹ 230.00 (Excl. Tax)


ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

CUDD4

الشركة المصنعة للمعدات الأصلية

ELMEX

وصف

Type Double-Level Terminal Block
Connection Method Screw Clamp
Mounting Type TS35/7.5, TS35/15, TS32 DIN Rail
Material Polyamide 6.6 Housing, CRCA Clamping
Standard Color Gray
Nominal Voltage (IEC) 500 V
Nominal Current (IEC) 24 A
Rated Cross Section (IEC) 2.5 mm²
Torque 0.4 Nm
Short-Time Withstand Current 0.3 kA
Rated Impulse Withstand Voltage 6 kV
ELMEX

CUDD4 | ELMEX | Double-Level Terminal Block

₹ 230.00
Type Double-Level Terminal Block
Connection Method Screw Clamp
Mounting Type TS35/7.5, TS35/15, TS32 DIN Rail
Material Polyamide 6.6 Housing, CRCA Clamping
Standard Color Gray
Nominal Voltage (IEC) 500 V
Nominal Current (IEC) 24 A
Rated Cross Section (IEC) 2.5 mm²
Torque 0.4 Nm
Short-Time Withstand Current 0.3 kA
Rated Impulse Withstand Voltage 6 kV
