SPARECRUX is NOT an authorized distributor for SCHNEIDER ELECTRIC

A9N16201 | SCHNEIDER ELECTRIC | Acti 9 xID Residual Circuit Breaker - 25 A - 2P - 30mA Class AC Instantaneous

₹ 4,508.54

₹ 3,820.80 (Excl. Tax)


ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

A9N16201

الشركة المصنعة للمعدات الأصلية

SCHNEIDER ELECTRIC

وصف

Product name Acti9 xID
Product or component type Residual current circuit breaker (RCCB)
Device short name xID
Poles description 2P
Neutral position Left
[In] rated current 25 A
Network type AC
Earth-leakage sensitivity 30 mA
Earth-leakage protection class Type AC
Rated breaking and making capacity 500 A conforming to EN/IEC 61008-1
Contact position indicator Yes
Control type Toggle
Local signalling ON, OFF, fault trip
Mounting mode Clip-on
Mounting support DIN rail
9 mm pitches 4
Height 81 mm
Width 36 mm
Depth 75 mm
Net weight 210 g
Colour White
Mechanical durability 4000 cycles
Electrical durability 4000 cycles
Locking options description Padlocking device
SCHNEIDER ELECTRIC

A9N16201 | SCHNEIDER ELECTRIC | Acti 9 xID Residual Circuit Breaker - 25 A - 2P - 30mA Class AC Instantaneous

₹ 3,820.80
Product name Acti9 xID
Product or component type Residual current circuit breaker (RCCB)
Device short name xID
Poles description 2P
Neutral position Left
[In] rated current 25 A
Network type AC
Earth-leakage sensitivity 30 mA
Earth-leakage protection class Type AC
Rated breaking and making capacity 500 A conforming to EN/IEC 61008-1
Contact position indicator Yes
Control type Toggle
Local signalling ON, OFF, fault trip
Mounting mode Clip-on
Mounting support DIN rail
9 mm pitches 4
Height 81 mm
Width 36 mm
Depth 75 mm
Net weight 210 g
Colour White
Mechanical durability 4000 cycles
Electrical durability 4000 cycles
Locking options description Padlocking device
