SPARECRUX is NOT an authorized distributor for WENGLOR

96733 | WENGLOR | Fiber-Optic Amplifier

₹ 28,025.00

₹ 23,750.00 (Excl. Tax)


ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

96733

الشركة المصنعة للمعدات الأصلية

WENGLOR

وصف

Optical Data - Range 3,000 mm
Switching Hysteresis < 15%
Light Source Infrared Light
Service Life (T = +25 °C) 100,000 h
Max. Ambient Light 10,000 Lux
Opening Angle 12°
Supply Voltage 10 ... 30 V DC
Current Consumption (Ub = 24 V) < 40 mA
Switching Frequency 100 Hz
Response Time 5 ms
Temperature Drift < 10%
Temperature Range -25 ... 60 °C
Switching Output Voltage Drop < 2.5 V
PNP Switching Output / Switching Current 200 mA
Residual Current Switching Output < 50 µA
Short Circuit Protection Yes
Reverse Polarity Protection Yes
Overload Protection Yes
Protection Class III
Mechanical Data - Setting Method Potentiometer
Housing Material Brass, nickel-plated
Optic Cover Plastic, PC
Full Encapsulation Yes
Degree of Protection IP65
Connection M12 × 1; 4-pin
Weight 126 g
Output / Adjustable Parameters PNP NC, PNP NO: Yes
Circuit: NC, NC+NO, NO
WENGLOR

96733 | WENGLOR | Fiber-Optic Amplifier

₹ 23,750.00
Optical Data - Range 3,000 mm
Switching Hysteresis < 15%
Light Source Infrared Light
Service Life (T = +25 °C) 100,000 h
Max. Ambient Light 10,000 Lux
Opening Angle 12°
Supply Voltage 10 ... 30 V DC
Current Consumption (Ub = 24 V) < 40 mA
Switching Frequency 100 Hz
Response Time 5 ms
Temperature Drift < 10%
Temperature Range -25 ... 60 °C
Switching Output Voltage Drop < 2.5 V
PNP Switching Output / Switching Current 200 mA
Residual Current Switching Output < 50 µA
Short Circuit Protection Yes
Reverse Polarity Protection Yes
Overload Protection Yes
Protection Class III
Mechanical Data - Setting Method Potentiometer
Housing Material Brass, nickel-plated
Optic Cover Plastic, PC
Full Encapsulation Yes
Degree of Protection IP65
Connection M12 × 1; 4-pin
Weight 126 g
Output / Adjustable Parameters PNP NC, PNP NO: Yes
Circuit: NC, NC+NO, NO
