750-610 | WAGO | 24 VDC Power Supply with Fuse Holder and Diagnostics

₹ 13,250.36

₹ 11,229.12 (Excl. Tax)


ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

750-610

الشركة المصنعة للمعدات الأصلية

WAGO

وصف

Property Value
Signal Type Voltage
Signal Type (Voltage) 24 VDC
Supply Voltage (System) 5 VDC; via data contacts
Supply Voltage (Field) 24 VDC (-25 … +30 %); via power jumper contacts
Power Supply Details Power via CAGE CLAMP® connection; transmission (field-side) via spring contact
Current Consumption (5 V System Supply) 5 mA
Current Carrying Capacity (Power Jumper Contacts) 6.3 A
Number of Outgoing Power Jumper Contacts 3
Width 12 mm / 0.472 inches
Height 100 mm / 3.937 inches
Depth 69.8 mm / 2.748 inches
Depth from Upper-Edge of DIN-Rail 62.6 mm / 2.465 inches
Mounting Type DIN-35 rail
Pluggable Connector Fixed
Housing Material Polycarbonate; Polyamide 6.6
Fire Load 1.398 MJ
Weight 46.8 g
WAGO

750-610 | WAGO | 24 VDC Power Supply with Fuse Holder and Diagnostics

₹ 11,229.12
Property Value
Signal Type Voltage
Signal Type (Voltage) 24 VDC
Supply Voltage (System) 5 VDC; via data contacts
Supply Voltage (Field) 24 VDC (-25 … +30 %); via power jumper contacts
Power Supply Details Power via CAGE CLAMP® connection; transmission (field-side) via spring contact
Current Consumption (5 V System Supply) 5 mA
Current Carrying Capacity (Power Jumper Contacts) 6.3 A
Number of Outgoing Power Jumper Contacts 3
Width 12 mm / 0.472 inches
Height 100 mm / 3.937 inches
Depth 69.8 mm / 2.748 inches
Depth from Upper-Edge of DIN-Rail 62.6 mm / 2.465 inches
Mounting Type DIN-35 rail
Pluggable Connector Fixed
Housing Material Polycarbonate; Polyamide 6.6
Fire Load 1.398 MJ
Weight 46.8 g
