SPARECRUX is NOT an authorized distributor for SICK SENSORS

6053545 | SICK SENSORS | UM12-1172271 Ultrasonic Distance Sensor

₹ 31,945.90

₹ 27,072.80 (Excl. Tax)


  Available for backorder, with an estimated lead time of 8 to 12 weeks.

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

6053545

الشركة المصنعة للمعدات الأصلية

SICK SENSORS

وصف

Operating range, limiting range 20 mm ... 150 mm, 250 mm
Target Natural objects
Resolution ≥ 0.069 mm
Repeatability ± 0.15 % 1)
Measurement accuracy ± 1 % 2)
Temperature compensation
Response time 24 ms 3)
Output time 8 ms
Dimensions (W x H x D) 12 mm x 12 mm x 60.1 mm
Design Cylindrical
Sending axis Straight
Housing material Metal (nickel-plated brass, PBT, ultrasonic transducer: polyurethane foam, glass epoxy resin)
Weight 15 g
Thread size M12 x 1
Connection type Male connector, M12, 4-pin



SICK SENSORS 6053545 UM12-1172271 Ultrasonic Distance Sensor
SICK SENSORS

6053545 | SICK SENSORS | UM12-1172271 Ultrasonic Distance Sensor

₹ 27,072.80
Operating range, limiting range 20 mm ... 150 mm, 250 mm
Target Natural objects
Resolution ≥ 0.069 mm
Repeatability ± 0.15 % 1)
Measurement accuracy ± 1 % 2)
Temperature compensation
Response time 24 ms 3)
Output time 8 ms
Dimensions (W x H x D) 12 mm x 12 mm x 60.1 mm
Design Cylindrical
Sending axis Straight
Housing material Metal (nickel-plated brass, PBT, ultrasonic transducer: polyurethane foam, glass epoxy resin)
Weight 15 g
Thread size M12 x 1
Connection type Male connector, M12, 4-pin
