SPARECRUX is NOT an authorized distributor for SICK SENSORS

6040876 | SICK SENSORS | LFV200-XXHCNTPV Level Sensor

₹ 47,769.23

₹ 40,482.40 (Excl. Tax)


  Available for backorder, with an estimated lead time of 8 to 12 weeks.

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

6040876

الشركة المصنعة للمعدات الأصلية

SICK SENSORS

وصف

Medium Fluids
Measurement Switch
Probe length 67 mm
Process pressure –1 bar ... 64 bar
Process temperature –40 °C ... +150 °C
Fill material density 0.7 g/cm³ ... 2.5 g/cm³
Supply voltage 9.6 V DC ... 35 V DC
Residual ripple ≤ 5 Vpp
Power consumption ≤ 10 mA
Initialization time < 2 s
VDE protection class 2
Connection type Valve plug DIN 43650
Output signal Transistor output PNP
Hysteresis 2 mm
Output current < 250 mA
Inductive load ≤ 1 H
Capacitive load 100 nF



SICK SENSORS 6040876 LFV200-XXHCNTPV Level Sensor
SICK SENSORS

6040876 | SICK SENSORS | LFV200-XXHCNTPV Level Sensor

₹ 40,482.40
Medium Fluids
Measurement Switch
Probe length 67 mm
Process pressure –1 bar ... 64 bar
Process temperature –40 °C ... +150 °C
Fill material density 0.7 g/cm³ ... 2.5 g/cm³
Supply voltage 9.6 V DC ... 35 V DC
Residual ripple ≤ 5 Vpp
Power consumption ≤ 10 mA
Initialization time < 2 s
VDE protection class 2
Connection type Valve plug DIN 43650
Output signal Transistor output PNP
Hysteresis 2 mm
Output current < 250 mA
Inductive load ≤ 1 H
Capacitive load 100 nF
