SPARECRUX is NOT an authorized distributor for LAPP GROUP

4520062U | LAPP GROUP | Single Core Cable, 1x2.5, Grey

₹ 2,919.45

₹ 2,474.11 (Excl. Tax)


ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

4520062U

الشركة المصنعة للمعدات الأصلية

LAPP GROUP

وصف

Specification Details
Product Type Single core cable
Weight 33 kg/km
Copper Index 24.000 kg/km
Single Core Packaging Type Ring
Nominal Voltage 1.1 kV AC rms (Indian standard)
Test Voltage 3 kV
Current Rating According To IS 3961
Cable Dimension 1×2.5
Conductor Cross-Section 2.5 mm²
Conductor Material Bare Copper
Conductor Design IEC 60228 class 5: fine-wire
Number of Cores 1
Nominal Outer Diameter 3.6 mm
Shape of Cable Round
Core Insulation Base Material Polyvinylchloride (PVC)
Cable Marking LAPP KABEL STUTTGART ÖLFLEX® UNIPLUS C.S Sq.mm 1100V CM/L NO ISI LOGO IS 694 FR RoHS CE METER MARKING
Single Core Color Grey
Single Core Identification Single-coloured
Application Area Fixed Installation, Flexible
Minimum Bending Radius (Fixed) 6× outer diameter / 21.6 mm
Minimum Bending Radius (Occasionally Moved) 8× outer diameter / 28.8 mm
Temperature (Fixed Installation) -40 °C to 80 °C
Temperature (Occasionally Moved) -15 °C to 70 °C
LAPP GROUP

4520062U | LAPP GROUP | Single Core Cable, 1x2.5, Grey

₹ 2,474.11
Specification Details
Product Type Single core cable
Weight 33 kg/km
Copper Index 24.000 kg/km
Single Core Packaging Type Ring
Nominal Voltage 1.1 kV AC rms (Indian standard)
Test Voltage 3 kV
Current Rating According To IS 3961
Cable Dimension 1×2.5
Conductor Cross-Section 2.5 mm²
Conductor Material Bare Copper
Conductor Design IEC 60228 class 5: fine-wire
Number of Cores 1
Nominal Outer Diameter 3.6 mm
Shape of Cable Round
Core Insulation Base Material Polyvinylchloride (PVC)
Cable Marking LAPP KABEL STUTTGART ÖLFLEX® UNIPLUS C.S Sq.mm 1100V CM/L NO ISI LOGO IS 694 FR RoHS CE METER MARKING
Single Core Color Grey
Single Core Identification Single-coloured
Application Area Fixed Installation, Flexible
Minimum Bending Radius (Fixed) 6× outer diameter / 21.6 mm
Minimum Bending Radius (Occasionally Moved) 8× outer diameter / 28.8 mm
Temperature (Fixed Installation) -40 °C to 80 °C
Temperature (Occasionally Moved) -15 °C to 70 °C
