SPARECRUX is NOT an authorized distributor for WAGO

282-402 | WAGO | Rail-Mount Terminal Block Jumper – Insulated, Gray

₹ 186.37

₹ 157.94 (Excl. Tax)


ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

282-402

الشركة المصنعة للمعدات الأصلية

WAGO

وصف

Specification Value
Rated current 41 A
Rated current (Ex e II) 35 A
Width 8 mm / 0.315 inches
Height 8 mm / 0.315 inches
Depth 24.6 mm / 0.969 inches
Jumper assignment 1-2
Color Gray
Material group I
Insulation material (main housing) Polyamide (PA66)
Flammability class per UL94 V0
Fire load 0.015 MJ
Weight 2.8 g
Processing temperature -35 … +85 °C
Continuous operating temperature -60 … +105 °C
WAGO

282-402 | WAGO | Rail-Mount Terminal Block Jumper – Insulated, Gray

₹ 157.94
Specification Value
Rated current 41 A
Rated current (Ex e II) 35 A
Width 8 mm / 0.315 inches
Height 8 mm / 0.315 inches
Depth 24.6 mm / 0.969 inches
Jumper assignment 1-2
Color Gray
Material group I
Insulation material (main housing) Polyamide (PA66)
Flammability class per UL94 V0
Fire load 0.015 MJ
Weight 2.8 g
Processing temperature -35 … +85 °C
Continuous operating temperature -60 … +105 °C
