SPARECRUX is NOT an authorized distributor for DWYER

2000-250CM | DWYER | Differential Pressure Gage Range 0-250 CM

₹ 8,631.70

₹ 7,315.00 (Excl. Tax)


ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

2000-250CM

الشركة المصنعة للمعدات الأصلية

DWYER

وصف

Feature Description
Bezel Provides flange for flush mounting in panel
Face Clear plastic, highly resistant to breakage, provides undistorted viewing of pointer and scale
Scale Precision litho-printed, accurate and easy to read
Pointer Red-tipped, made of heat-treated aluminum tubing, rigidly mounted on helix shaft
Pointer Stops Molded rubber stops prevent pointer over-travel without damage
"Wishbone" Assembly Provides mounting for helix, helix bearings, and pointer shaft
Bearings Jeweled, shock-resistant, virtually friction-free motion, damped with high viscosity silicone fluid
Zero Adjustment Convenient screw in plastic cover, accessible without removal, O-ring sealed for pressure tightness
Helix Precision alloy of high magnetic permeability, mounted in jeweled bearings, moves pointer across scale
Range Spring Flat spring steel, small motion amplitude for consistency and long life, adjustable for calibration
Diaphragm Silicone rubber with integrally molded O-ring, supported by plates, sealed with retaining ring, restricted motion prevents overpressure damage
Case Die cast aluminum, precision made, iridite-dipped for 168-hour salt spray corrosion resistance
Finish Baked dark gray hammerloid exterior
Case Size Single size used for all standard pressure options, suitable for surface and flush mounting
DWYER

2000-250CM | DWYER | Differential Pressure Gage Range 0-250 CM

₹ 7,315.00
Feature Description
Bezel Provides flange for flush mounting in panel
Face Clear plastic, highly resistant to breakage, provides undistorted viewing of pointer and scale
Scale Precision litho-printed, accurate and easy to read
Pointer Red-tipped, made of heat-treated aluminum tubing, rigidly mounted on helix shaft
Pointer Stops Molded rubber stops prevent pointer over-travel without damage
"Wishbone" Assembly Provides mounting for helix, helix bearings, and pointer shaft
Bearings Jeweled, shock-resistant, virtually friction-free motion, damped with high viscosity silicone fluid
Zero Adjustment Convenient screw in plastic cover, accessible without removal, O-ring sealed for pressure tightness
Helix Precision alloy of high magnetic permeability, mounted in jeweled bearings, moves pointer across scale
Range Spring Flat spring steel, small motion amplitude for consistency and long life, adjustable for calibration
Diaphragm Silicone rubber with integrally molded O-ring, supported by plates, sealed with retaining ring, restricted motion prevents overpressure damage
Case Die cast aluminum, precision made, iridite-dipped for 168-hour salt spray corrosion resistance
Finish Baked dark gray hammerloid exterior
Case Size Single size used for all standard pressure options, suitable for surface and flush mounting
