SPARECRUX is NOT an authorized distributor for FESTO

177691 | FESTO | Push-in L-connector CQL-12

₹ 322.62

₹ 273.41 (Excl. Tax)


ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

177691

الشركة المصنعة للمعدات الأصلية

FESTO

وصف

Parameter Specification
Nominal size 8.65 mm
Mounting position Optional
Size of pack 1
Design principle Push-pull principle
Operating pressure (complete temperature range) -0.95 bar ... 7 bar
Temperature-dependent operating pressure -0.95 bar ... 15 bar
Operating medium Compressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required)
Corrosion resistance class (CRC) 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364 zone III
Suitable for use with food See supplementary material information
Ambient temperature -25 °C ... 70 °C
Product weight 16 g
Pneumatic connection, port 1 For pipe/tubing outside diameter of 12 mm
Pneumatic connection, port 2 For pipe/tubing outside diameter of 12 mm
Note on materials RoHS-compliant
Material housing POM
Material release ring POM
Material tubing clamp component High-alloy stainless steel
FESTO

177691 | FESTO | Push-in L-connector CQL-12

₹ 273.41
Parameter Specification
Nominal size 8.65 mm
Mounting position Optional
Size of pack 1
Design principle Push-pull principle
Operating pressure (complete temperature range) -0.95 bar ... 7 bar
Temperature-dependent operating pressure -0.95 bar ... 15 bar
Operating medium Compressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required)
Corrosion resistance class (CRC) 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364 zone III
Suitable for use with food See supplementary material information
Ambient temperature -25 °C ... 70 °C
Product weight 16 g
Pneumatic connection, port 1 For pipe/tubing outside diameter of 12 mm
Pneumatic connection, port 2 For pipe/tubing outside diameter of 12 mm
Note on materials RoHS-compliant
Material housing POM
Material release ring POM
Material tubing clamp component High-alloy stainless steel
