SPARECRUX is NOT an authorized distributor for FESTO

This product has been discontinued, and manufacturer warranty or support may no longer be available.

172962 | FESTO | On/off Valve HEE-D-MAXI-24

₹ 8,241.03

₹ 6,983.92 (Excl. Tax)


ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

172962

الشركة المصنعة للمعدات الأصلية

FESTO

وصف

Specification Details
Design Piston gate valve
Type of actuation Electric
Sealing principle Soft
Exhaust-air function Without flow control option
Manual override Detenting
Type of reset Mechanical spring
Type of piloting Pilot actuated
Symbol 00991008
Valve function 3/2-way, closed, monostable
Operating pressure 0.25 MPa ... 1.6 MPa (2.5 bar ... 16 bar)
Lap Overlap
Duty cycle 100%
Characteristic coil data 24 V DC: 2.5 W
Permissible voltage fluctuations ±10%
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4], Inert gases
Note on operating and pilot medium Lubricated operation possible (lubrication required if used)
Corrosion resistance class (CRC) 2 - Moderate corrosion stress
Note on materials RoHS-compliant
LABS (PWIS) conformity VDMA24364-B1/B2-L
Media temperature -10 °C ... 60 °C
Ambient temperature -10 °C ... 60 °C
Type of mounting With accessories
