SPARECRUX is NOT an authorized distributor for FESTO

This product has been discontinued, and manufacturer warranty or support may no longer be available.

162969 | FESTO | One-way Flow Control Valve GRLA-3/8-QS-6-RS-B

₹ 1,697.19

₹ 1,438.30 (Excl. Tax)

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

162969

الشركة المصنعة للمعدات الأصلية

FESTO

وصف
Parameter Specification
Reference / Type Code 162969 / GRLA‑3/8‑QS‑6‑RS‑B
Valve Function One‑way flow control for exhaust air (non‑return)
Pneumatic Connection – Port 1 QS‑6 (push‑in connector 6 mm)
Pneumatic Connection – Port 2 G 3/8 (female thread)
Actuation Type Manual (knurled screw adjuster)
Mounting Type Screw‑in
Operating Pressure (entire temp range) 0.2 bar ... 10 bar
Standard Nominal Flow – Control Direction 530 L/min
Standard Nominal Flow – Non‑Return Direction 400 ... 550 L/min
Flow at 6 bar → 0 bar (Control) 720 L/min
Flow at 6 bar → 0 bar (Non‑Return) 600 ... 750 L/min
Ambient Temperature Range -10 °C ... 60 °C
Medium Temperature Range -10 °C ... 60 °C
Storage Temperature -10 °C ... 40 °C
Operating Medium Compressed air to ISO 8573‑1:2010 [7:4:4]
Lubrication Note Oil‑lubricated operation possible (and required)
Explosion Protection Zones (ATEX) Zones 1, 2, 21, 22 (certificate must be observed)
Nominal Tightening Torque 12.5 Nm (±20%)
Permitted Actuation Torque (Adjusting Screw) 0.4 Nm
Product Weight ~40 g
Material – Screwed Stud / Knurled Head Wrought aluminium alloy
Material – Seals NBR, TPE‑U (PU)
Material – Release Ring POM
Material – Swivel Connection PBT‑reinforced
Compliance Notes RoHS‑compliant
Symbol 00991452
GTIN / EAN 4052568012830
FESTO
