SPARECRUX is NOT an authorized distributor for SICK SENSORS

1211095 | SICK SENSORS | SGS4-F140P7PS1W02 Automation Light Grid

₹ 75,026.29

₹ 63,581.60 (Excl. Tax)


  Available for backorder, with an estimated lead time of 8 to 12 weeks.

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

1211095

الشركة المصنعة للمعدات الأصلية

SICK SENSORS

وصف

Sensor principle Sender/receiver
Minimum detectable object (MDO) Parallel beam, 45 mm
Beam separation 40 mm
Optical light exit Flat
Number of beams 36
Detection height 1,400 mm
Parameterization None
Cross beam/parallel beam Parallel beam active
Light source Infrared light
Wave length 950 nm
Supply voltage Vs DC24 V, ± 20 %
Power consumption receiver ≤ 70 mA
Ripple < 5 Vpp
Output current Imax. 100 mA
Output load, capacitive 100 nF



SICK SENSORS 1211095 SGS4-F140P7PS1W02 Automation Light Grid
SICK SENSORS

1211095 | SICK SENSORS | SGS4-F140P7PS1W02 Automation Light Grid

₹ 63,581.60
Sensor principle Sender/receiver
Minimum detectable object (MDO) Parallel beam, 45 mm
Beam separation 40 mm
Optical light exit Flat
Number of beams 36
Detection height 1,400 mm
Parameterization None
Cross beam/parallel beam Parallel beam active
Light source Infrared light
Wave length 950 nm
Supply voltage Vs DC24 V, ± 20 %
Power consumption receiver ≤ 70 mA
Ripple < 5 Vpp
Output current Imax. 100 mA
Output load, capacitive 100 nF
