SPARECRUX is NOT an authorized distributor for LAPP GROUP

1119952 | LAPP GROUP | Control Cable, 2x2.5, U0/U: 300/500 V, Pvc

₹ 99.26

₹ 84.12 (Excl. Tax)


ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

1119952

الشركة المصنعة للمعدات الأصلية

LAPP GROUP

وصف

Specification Details
Type Control line
Cable details Structure mm²: 2X2.5 mm²
Cable Outer Diameter 7.5 mm
Rated Voltage Uo/U: 300V/500V
Minimum Bending Radius Moves: 15 × Outer diameter
Fixed: 4 × Outer diameter
Temperature Range Moves: -5°C to +70°C
Colour Outer sheath: Silver grey RAL 7001
Cores: Black with printed numbers
Range of Application Energy guiding chains: No
Applications - For flexible applications without forced guidance and without tensile load.
- Suitable for dry and damp rooms.
Fire Behaviour - Flame-retardant
- Self-extinguishing
- Flame-retardant according to IEC 60332-1-2
Chemical Resistance Chemically resistant
Wire Per Meter
LAPP GROUP

1119952 | LAPP GROUP | Control Cable, 2x2.5, U0/U: 300/500 V, Pvc

₹ 84.12
Specification Details
Type Control line
Cable details Structure mm²: 2X2.5 mm²
Cable Outer Diameter 7.5 mm
Rated Voltage Uo/U: 300V/500V
Minimum Bending Radius Moves: 15 × Outer diameter
Fixed: 4 × Outer diameter
Temperature Range Moves: -5°C to +70°C
Colour Outer sheath: Silver grey RAL 7001
Cores: Black with printed numbers
Range of Application Energy guiding chains: No
Applications - For flexible applications without forced guidance and without tensile load.
- Suitable for dry and damp rooms.
Fire Behaviour - Flame-retardant
- Self-extinguishing
- Flame-retardant according to IEC 60332-1-2
Chemical Resistance Chemically resistant
Wire Per Meter
