SPARECRUX is NOT an authorized distributor for SICK SENSORS

1093949 | SICK SENSORS | IMI30-10BNSNC0S Inductive Proximity Sensor

₹ 14,286.50

₹ 12,107.20 (Excl. Tax)


  Available for backorder, with an estimated lead time of 8 to 12 weeks.

ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

1093949

الشركة المصنعة للمعدات الأصلية

SICK SENSORS

وصف

Housing Metric
Thread size M30 x 1.5
Diameter Ø 30 mm
Sensing range Sn 10 mm
Safe sensing range Sa 8.1 mm
Installation type Flush
Switching frequency 50 Hz
Connection type Male connector M12, 4-pin
Housing material Stainless steel V4A, DIN 1.4404 / AISI 316L
Sensing face material Stainless steel V4A, DIN 1.4404 / AISI 316L
Housing length 65.3 mm
Thread length 46.3 mm
Tightening torque, max. ≤ 100 Nm



SICK SENSORS 1093949 IMI30-10BNSNC0S Inductive Proximity Sensor
SICK SENSORS

1093949 | SICK SENSORS | IMI30-10BNSNC0S Inductive Proximity Sensor

₹ 12,107.20
Housing Metric
Thread size M30 x 1.5
Diameter Ø 30 mm
Sensing range Sn 10 mm
Safe sensing range Sa 8.1 mm
Installation type Flush
Switching frequency 50 Hz
Connection type Male connector M12, 4-pin
Housing material Stainless steel V4A, DIN 1.4404 / AISI 316L
Sensing face material Stainless steel V4A, DIN 1.4404 / AISI 316L
Housing length 65.3 mm
Thread length 46.3 mm
Tightening torque, max. ≤ 100 Nm
