SPARECRUX is NOT an authorized distributor for RITTAAL

1060500 | RITTAL | Enclosure with Door of Sheet Steel

₹ 107,122.76

₹ 90,782.00 (Excl. Tax)


ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

1060500

الشركة المصنعة للمعدات الأصلية

RITTAAL

وصف

Specification Details
Material Housing: Carbon steel
Door: Carbon steel, all-round foamed-in PU seal
Surface Finish Housing and door: Dipcoat primed, powder-coated on the outside, textured paint
Mounting panel: Zinc-plated
Color RAL 7035
Supply Includes Housing with hinged door(s), of all-round solid construction
Flange (gland) plate(s) in enclosure base
Mounting panel
Lock: 3 mm double-bit
Protection Category NEMA NEMA 4
Protection Category IP (EN 60 529) IP 66
IK Code IK08
Dimensions Width: 600 mm (23.6˝)
Height: 600 mm (23.6˝)
Depth: 210 mm (8.27˝)
Material Thickness - Door 1.75 mm (0.07˝)
Material Thickness - Enclosure 1.38 mm (0.05˝)
Material Thickness - Mounting Plate 2.5 mm (0.1˝)
Mounting Plate Dimensions (W x H) 549 mm x 570 mm (21.6˝ x 22.4˝)
Number of Doors 1
Interchangeable Door Catch Yes
RITTAAL
