SPARECRUX is NOT an authorized distributor for SCHMERSAL

101147465 | SCHMERSAL | Safety Switch With Separate Drive

₹ 10,931.52

₹ 9,264.00 (Excl. Tax)


ضمان

نقدم ضمانًا لمدة عام واحد من تاريخ الشراء للمنتجات الجديدة. بالإضافة إلى ذلك، تأتي المنتجات الفائضة/المستعملة مع ضمان لمدة 30 يومًا .

التسليم والشحن

نهدف إلى معالجة الطلبات خلال ٥-٧ أيام عمل . تختلف خيارات الشحن باختلاف الموقع، مع توفير خدمة التتبع؛ الشحن الدولي متاح مع تحمل العميل مسؤولية الرسوم الجمركية.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

رقم قطعة الشركة المصنعة (MPN)

101147465

الشركة المصنعة للمعدات الأصلية

SCHMERSAL

وصف

Protection Level IP67 to IEC/EN 60529
Type AZ 17-02ZRK-2243-5.0M
Body Material Plastic, glass fiber reinforced thermoplastic, self-extinguishing
Contact Material Silver
Delivery Set Drives must be ordered separately
Current, Load Mode DC13 4 A
Voltage, Load Mode DC13 24 VDC
Current, Load Mode AC-15 4 A
Voltage, Load Mode AC15 230 VAC
Thermal Withstand Current 10 A
Nominal Impulse Withstand Voltage 4 kV
Response Speed, Max 2 m/s
Opening Force 17 N
Forced Opening Stroke 11 mm
Mechanical Life 1,000,000 operations
Mean Time Between Failures 20 years
Standards ISO 13849-1
Certificates BG, CCC, EAC, CNCA
EAN (Barcode) 4030661282091
SCHMERSAL

101147465 | SCHMERSAL | Safety Switch With Separate Drive

₹ 9,264.00
Protection Level IP67 to IEC/EN 60529
Type AZ 17-02ZRK-2243-5.0M
Body Material Plastic, glass fiber reinforced thermoplastic, self-extinguishing
Contact Material Silver
Delivery Set Drives must be ordered separately
Current, Load Mode DC13 4 A
Voltage, Load Mode DC13 24 VDC
Current, Load Mode AC-15 4 A
Voltage, Load Mode AC15 230 VAC
Thermal Withstand Current 10 A
Nominal Impulse Withstand Voltage 4 kV
Response Speed, Max 2 m/s
Opening Force 17 N
Forced Opening Stroke 11 mm
Mechanical Life 1,000,000 operations
Mean Time Between Failures 20 years
Standards ISO 13849-1
Certificates BG, CCC, EAC, CNCA
EAN (Barcode) 4030661282091
