XPSBF1132P | SCHNEIDER ELECTRIC | Module XPSBF - two-hand control - 24 V DC

₹ 39,235.00

₹ 33,250.00 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

XPSBF1132P

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Description
Manufacturer Schneider Electric (Preventa XPSBF Series)
Module Type Two‑Hand Control Safety Relay
Supply Voltage 24 V DC (±20 %)
Output Contacts 2 × NO (volt‑free relay outputs) + 2 × solid‑state auxiliary outputs
Relay Output Rating 4.2 A per relay; inrush 1800 VA AC‑15 (C300), holding 180 VA
Solid‑State Output Rating 20 mA @ 24 V DC
Min. Relay Output Current / Voltage 10 mA / 17 V
Input Compatibility Two‑hand control (1 NC + 1 NO), EN 574 / ISO 13851‑III C
Synchronization Time 0.5 s between inputs
Response Time ≤ 20 ms on input open
Power Consumption ≤ 2.5 W
Rated Insulation Voltage (Ui) 300 V (Pollution Degree 2)
Impulse Withstand Voltage (Uimp) 4 kV, Overvoltage Category III
Indicator LEDs 3 built‑in status LEDs
Terminal Type Captive screw clamp, removable terminal block (flexible/solid up to 2.5 mm²)
Mounting 35 mm DIN rail
Weight ≈ 0.15 kg
Enclosure Rating IP20 (terminals), IP40 (enclosure)
Operating Temperature −10 °C to +55 °C; Storage: −25 °C to +85 °C
Safety Standards EN 574 type III C / ISO 13851; EN/IEC 60204‑1; EN/IEC 60947‑5‑1
Performance Level / SIL PL e (Cat 4), SIL CL3
Reliability MTTFd 50.1 years; PFHd 1.3 × 10−8/h
Certifications UL, CSA, TÜV
