SPARECRUX is NOT an authorized distributor for SCHNEIDER ELECTRIC

XB7EV05GP | SCHNEIDER ELECTRIC | Monolithic pilot light, plastic, yellow, Ø22, integral LED, 110...120 V AC

₹ 413.65

₹ 350.55 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

XB7EV05GP

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Description

Series Harmony XB7
Model XB7EV05GP
Lens Color Yellow
LED Voltage 110–120 VAC (50/60 Hz)
Current Consumption ~18–21 mA
Panel Cut-out Size Ø22 mm standard cut-out
Front IP Rating IP65 (rear IP20)
Terminal Type Screw clamp
Material & Build Double-insulated plastic with monolithic design
Operating Temperature –25 °C to +70 °C
Electrical Standards IEC 60947‑5‑1, UL 508, CSA C22.2, JIS C8201‑5‑1
Insulation & Overvoltage Ui = 250 V, Uimp = 6 kV; Overvoltage Category II
Life Expectancy ~70,000 hours at rated conditions
Weight Approx. 0.02 kg
Certifications Green Premium, CE, UL, CSA, RoHS compliant



SCHNEIDER ELECTRIC

XB7EV05GP | SCHNEIDER ELECTRIC | Monolithic pilot light, plastic, yellow, Ø22, integral LED, 110...120 V AC

₹ 350.55
Series Harmony XB7
Model XB7EV05GP
Lens Color Yellow
LED Voltage 110–120 VAC (50/60 Hz)
Current Consumption ~18–21 mA
Panel Cut-out Size Ø22 mm standard cut-out
Front IP Rating IP65 (rear IP20)
Terminal Type Screw clamp
Material & Build Double-insulated plastic with monolithic design
Operating Temperature –25 °C to +70 °C
Electrical Standards IEC 60947‑5‑1, UL 508, CSA C22.2, JIS C8201‑5‑1
Insulation & Overvoltage Ui = 250 V, Uimp = 6 kV; Overvoltage Category II
Life Expectancy ~70,000 hours at rated conditions
Weight Approx. 0.02 kg
Certifications Green Premium, CE, UL, CSA, RoHS compliant
