USCC3I | MERSEN | Fuse Holder 600V 30A 3P CC ULTSFE W/IND

₹ 16,030.03

₹ 13,584.77 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

USCC3I

Original Equipment Manufacturer

MERSEN

Description

Attribute Details
Item Number USCC3I
Description Fuse Holder UltraSafe™ 600VAC/600VDC Class CC 30A 3-Pole LED Pressure Plate IP20
EAN/UPC Code 782001829919
Rated Voltage (AC UL) 600 V
Rated Voltage (DC UL) 600 V
Frequency 50/60 Hz
Ampere Rating 30 A
ROHS Compliant Yes
AC or DC AC/DC
Fuse Class Class CC
Short Circuit Current Rating 200 kA
Fuse Type/Class Class CC
Indication System Yes
Indication System Type LED
Number of Poles 3-Pole
Wiring Range Cu #6–14
Fuse Installation Method Clip-in
Torque Rating 1.695 N·m
Max Fuse Rating 30 A
Installation Mounting DIN Rail
Product Width 52.6 mm
Product Length 78 mm
Product Height 58.9 mm
Product Weight 0.195 kg
Sell Pack Quantity 4 EA
Sell Pack Weight 0.8165 kg
Sell Pack Width 88.9 mm
Sell Pack Length 215.9 mm
Sell Pack Height 67.6 mm
Product Group Fuse Holders
Body/Insulating Material Glass Filled Polycarbonate
