U2297-78 | TURCK | Actuator and Sensor Cordset, Connection Cordset

₹ 4,410.01

₹ 3,737.30 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

U2297-78

Original Equipment Manufacturer

TURCK

Description
Attribute Details
Primary Brand Turck
Main Function Cable
Product Series / Family Connectivity > Cables > Open-ended cordsets > Straight connector to bare leads
Sub-range Name M12 eurofast to bare leads
Function Single-ended mating cable / cordset
Design Foil shield and drain wire connected to the pin
Number of Circuits 4-wire
Rated Current 4 A
Rated Voltage (AC) 250 Vac
Color Gray sheath
Wire Colors BN (Brown) / WH (White) / BU (Blue) / BK (Black) / GY (Gray)
Cable Diameter (O.D.) 5.3 mm
Connection Type 5-pin M12 eurofast female connector (T-barb fitting), bare end flying leads
Conductor Cross-section 4 x #22 AWG (sometimes noted as 5 x 22 AWG — may include shield)
Cable Length 6 m (19 ft)
Degree of Protection IP68, NEMA 1, NEMA 3, NEMA 4, NEMA 6P
Material Nickel-plated brass coupling nut, PVC jacket
Irradiation Resistance RFI/EMI shielding
Cable Type Used RF50577-M
Order Code / SKU U2297-78
Product Status Commercialized
Equivalent Part Numbers RK4.5T-6/S653, RK-4.5T-6/S653, RK45T6S653
Standards Compliance UL, CSA, ITC, PLTC
