SH 1 1/8 | MARTIN | QD Bushing

₹ 4,182.45

₹ 3,544.45 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

SH 1 1/8

Original Equipment Manufacturer

MARTIN

Description
Field Details
Bushing Size SH
Bore Type Finished w/ Keyway
Keyway Size 1/4 × 1/8 in
Bore Diameter 1.1250 in
Flange Outside Diameter 2.687 in
Flange Thickness 0.4375 in
Length Through Bore 1.3125 in
Material Cast Iron
Screw Torque 108 in‑lb (?)
Barrel Diameter 1.871 in
Stocked Finished Bore 1.125 in
Barrel Length 0.875 in
Storage Dimension Height 1.375 in
Bolt Circle Diameter 2‑1/4 in
Storage Dimension Length 2.875 in
Number Of Bolt Holes 3
Screw Thread Size 1/4‑20 in
Screw Length 1‑3/8 in
Storage Dimension Width 2.875 in
Manufacturer Catalog Click here
Product Brochure Click here
UPC_NO 697950037240
