SPARECRUX is NOT an authorized distributor for SEALMASTER

SFC-24T | SEALMASTER | Four-Bolt Piloted Flange Ball Bearing Unit

₹ 38,548.95

₹ 32,668.60 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

SFC-24T

Original Equipment Manufacturer

SEALMASTER

Description
Field Details
Product Type Flange‑Mount Ball Bearing Units
Bore Diameter 1‑1/2 in
Housing Material Cast Iron
Duty Type Standard Duty
Bolt Center to Center Length 4.3750 in
Overall Length 5.2500 in
Bolt Circle Diameter 4.3750 in
Locking Device Concentric Collar
Expansion Type Non‑Expansion Bearing (Fixed)
Seal Type Felt Labyrinth Seal
Overall Length (Diameter) 5.2500 in
Overall Height 1.5625 in
Housing Width 5.2500 in
Lubrication Type Lithium Complex NLGI 2 Grease
Overall Width 5.2500 in
Bore Type Straight
Inner Ring Width 2.0630 in
Bearing Material 52100 Bearing Steel, Black Oxided
Radial Dynamic Load Capacity 7340 lbf
Radial Static Load Capacity 4467 lbf
Length Through Bore 2.0630 in
Operating Temperature Range -20° to 400 °F
Max Operating Temperature 400 °F
Finish/Coating Gray
Pilot Diameter 3.6250 in
Bolt Size 0.3750 in
Max RPM 1803 rpm
SEALMASTER
