SFC-20TC | SEALMASTER | Bearing

₹ 30,648.14

₹ 25,973.00 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

SFC-20TC

Original Equipment Manufacturer

SEALMASTER

Description
Parameter Specification
Product Type Flange‑Mount Ball Bearing Units
Length 7.35 (in)
Width 8.55 (in)
Bore Diameter 1 ‑ 1/4 in
Housing Material Cast Iron
Duty Type Standard Duty
Bolt Center To Center Length 4.1250 in
Bolt Circle Diameter 4.1250 in
Locking Device Concentric Collar
Expansion Type Non‑Expansion Bearing (Fixed)
Seal Type Contact Seal
Overall Length Diameter 5.0000 in
Housing Width 1.3125 in
Lubrication Type Lithium Complex NLGI 2 Grease
Bore Type Straight
Inner Ring Width 1.7500 in
Bearing Material 52100 Bearing Steel, Black Oxided
Operating Temperature Range ‑20° to 220 °F
Max Operating Temperature 220 °F
Finish / Coating Gray
Pilot Diameter 3.3750 in
Bolt Size 0.3750 in
Max RPM 4,650 rpm
Series Standard
Replacement Bearing 2‑14TC
Color Gray
Lubrication (repeated) Lithium Complex NLGI 2 Grease
Manufacturer Catalog Number SFC‑20TC
