SPARECRUX is NOT an authorized distributor for SCHNEIDER ELECTRIC

This product has been discontinued, and manufacturer warranty or support may no longer be available.

RPM22JD | SCHNEIDER ELECTRIC | Power Plug-in Relay, Harmony RPM, 2 C/O (DPDT), 15 A, with LED and Lockable Test Button, 12 V DC Coil

₹ 1,219.09

₹ 1,033.13 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

RPM22JD

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Description

Coil Voltage 12 V DC
Coil Power ~0.85 W (160 Ω)
Contact Form DPDT (2 C/O)
Rated Current 15 A @ 250 VAC / 28 V DC
Switching Capacity 3750 VA AC / 420 W DC
Indicators LED + lockable test button
Durability Mechanical: 10M cycles, Electrical: 100 k cycles
Operate/Release Time ~20 ms
Protection Rating IP40
Ambient Temp –40 °C to +55 °C
Mounting Socketable quick‑connect pins
Standards & Approvals CSA, UL, EN/IEC, RoHS
SCHNEIDER ELECTRIC

RPM22JD | SCHNEIDER ELECTRIC | Power Plug-in Relay, Harmony RPM, 2 C/O (DPDT), 15 A, with LED and Lockable Test Button, 12 V DC Coil

₹ 1,033.13
Coil Voltage 12 V DC
Coil Power ~0.85 W (160 Ω)
Contact Form DPDT (2 C/O)
Rated Current 15 A @ 250 VAC / 28 V DC
Switching Capacity 3750 VA AC / 420 W DC
Indicators LED + lockable test button
Durability Mechanical: 10M cycles, Electrical: 100 k cycles
Operate/Release Time ~20 ms
Protection Rating IP40
Ambient Temp –40 °C to +55 °C
Mounting Socketable quick‑connect pins
Standards & Approvals CSA, UL, EN/IEC, RoHS
