LXD3N7 | SCHNEIDER ELECTRIC | TeSys D - contactor coil - LXD3 - 415 V AC 50/60 Hz for 40… 65 A contactor

₹ 5,044.50

₹ 4,275.00 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

LXD3N7

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Description
Manufacturer Schneider Electric (TeSys D Series)
Device Type Contactor Coil for 40…65 A contactors
Control Coil Voltage (Uc) 415 V AC ±10 %, 50/60 Hz
Average Resistance ≈ 635 Ω @ 20 °C (68 °F)
Inductance (closed circuit) ≈ 35.6 H
Compatibility LC1D40A…LC1D65A; LC1DT60A; LC1DT80A
Coil Technology Standard, without built-in suppressor module
Drop‑out Voltage 0.3…0.6 × Uc at 50/60 Hz (at ≤60 °C)
Operate Voltage Range 0.8…1.1 × Uc (50 Hz); 0.85…1.1 × Uc (60 Hz)
Inrush Power 160 VA (cos φ ≈ 0.75 at 20 °C)
Hold‑in Power 15 VA (cos φ ≈ 0.3 at 20 °C)
Heat Dissipation ≈ 4–5 W at 50/60 Hz
Mechanical Durability ≈ 6 million operations
Maximum Operating Rate Up to 3600 cycles/hour at ≤60 °C
Ambient Operating Temp. −5 °C to +60 °C
Net Weight ≈ 0.07 kg (0.15 lb)
