LV516462 | SCHNEIDER ELECTRIC | Easypact CVS - CVS160N Circuit Breaker - 3P/3d

₹ 13,199.78

₹ 11,186.25 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

LV516462

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Description

Manufacturer Schneider Electric – EasyPact CVS series
Device Type Circuit Breaker (MCCB) – CVS160N, 3P/3d
Rated Current (In) 125 A @ 40 °C
Trip Unit TM‑D Thermal‑Magnetic (fixed settings)
Poles 3‑pole + 3d detection
Breaking Capacity (Icu) 50 kA @ 380–415 VAC; 40 kA @ 440 VAC; 80 kA @ 220–240 VAC
Utilisation Category Category A (IEC 60947‑2)
Service Breaking Capacity (Ics) 50 kA @ 380–415 VAC; 30 kA @ 440 VAC
Rated Impulse Voltage (Uimp) 8 kV
Network Frequency 50/60 Hz
Mechanical Durability 25,000 cycles
Electrical Durability 12,000 cycles @ In @ 415 VAC
Dimensions (H×W×D) 161 × 105 × 86 mm
Weight ≈ 1.5 kg
Mounting Fixed back‑plate mounting
Connection Terminals Screw connections, 35 mm pitch
Protection Rating IP40; Class II shock protection
Operating Temp. −25 to +70 °C (storage −50 to +85 °C)
