SPARECRUX is NOT an authorized distributor for SCHNEIDER ELECTRIC

LR2 K0308 | SCHNEIDER ELECTRIC | TeSys K Differential Thermal Overload Relay, 1.8–2.6 A, Class 10A, 3‑Pole Motor Protection

₹ 9,015.40

₹ 7,640.17 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

LR2 K0308

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Description

Manufacturer Schneider Electric (TeSys K Series)
Device Type Differential thermal overload relay, 3‑Pole
Rated Current Range 1.8…2.6 A adjustable (Class 10A trip)
Contactor Compatibility LC1K, LP1K, LP4K, LC7K series
Auxiliary Contacts 1 NO + 1 NC (signalling)
Rated Insulation Voltage (Ui) 690 VAC (IEC); 600 VAC (UL/CSA)
Frequency Rating Up to 400 Hz
Mounting Direct under contactor or separate via block LA7 K0064
Trip & Reset Controls Manual or automatic reset selector; red trip test button; yellow trip flag indicator; blue reset button
Thermal Protection Ambient compensated; phase failure sensitive
Dimensions (H×W×D) 58 × 45 × 65 mm
Weight ≈ 0.145 kg
Operating Temperature −5 °C to +60 °C
Standards & Certifications IEC 60947‑4‑1, UL 508, CSA, CCC, EAC; Green Premium / RoHS compliant
